turck TBEN-RFID Series User Manual

Commissioning
Connecting the device to a Modbus master with CODESYS
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 49
Description Register Bit offset Bit length
Channel 0 Channel 1
Antenna detuned 0x0002 0x004E 4 1
Parameter not supported by
read/write head
0x0002 0x004E 5 1
Read/write head reports error 0x0002 0x004E 6 1
Expected read/write head not
connected
0x0002 0x004E 7 1
Length 0x0003 0x004F 0 16
Error code 0x0004 0x0050 0 16
Tag counter 0x0005 0x0051 0 16
Data (bytes) available 0x0006 0x0052 0 16
Read fragment No. 0x0007 0x0053 0 8
Write fragment No. 0x0007 0x0053 8 8
Read/write head 1 —
Tag in detection range
0x000A 0x0056 0 1
… … … … 1
Read/write head 16 —
Tag in detection range
0x000A 0x0056 15 1
Read/write head 17 —
Tag in detection range
0x000B 0x0057 0 1
… … … … 1
Read/write head 32 —
Tag in detection range
0x000B 0x0057 15 1
Read data Byte 0 0x000C 0x0058 0 8
Read data Byte 1 0x000C 0x0058 8 8
Read data Byte 2 0x000D 0x0059 0 8
Read data Byte 3 0x000D 0x0059 8 8
… … … … 8
Read data Byte 14 0x0013 0x005F 0 8
Read data Byte 15 0x0013 0x005F 8 8
… … … … 8
Read data Byte 64 0x002C 0x007B 0 8
Read data Byte 65 0x002C 0x007B 8 8
… … 0x0000 … 8
Read data Byte 126 0x004B 0x0097 0 8
Read data Byte 127 0x004B 0x0097 8 8
