turck TBEN-RFID Series User Manual

Commissioning
Connecting the device to a Modbus master with CODESYS
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 50
RFID channels — process output data
Description Register Bit offset Bit length
Channel 0 Channel 1
Command code 0x0800 0x084C 0 16
Loop counter 0x0801 0x084D 0 8
Memory area (only UHF) 0x0801 0x084D 8 8
Start address 0x0802 0x084E 0 32
Length 0x0804 0x0851 0 16
Length UID/EPC 0x0805 0x0851 0 8
Antenna No. 0x080A 0x0856 0 8
Timeout 0x0806 0x0852 0 16
Read fragment No. 0x0807 0x0853 0 8
Write fragment No. 0x0807 0x0853 8 8
Write data Byte 0 0x080C 0x0858 0 8
Write data Byte 1 0x080C 0x0858 8 8
… … … … 8
Write data Byte 14 0x0813 0x085F 0 8
Write data Byte 15 0x0813 0x085F 8 8
… … … … 8
Write data Byte 64 0x0813 0x0878 0 8
Write data Byte 65 0x0813 0x0878 8 8
… … … … 8
Write data Byte 126 0x084B 0x0897 0 8
Write data Byte 127 0x084B 0x0897 8 8
