turck TBEN-RFID Series User Manual

Commissioning
Connecting the device to a Modbus master with CODESYS
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 51
RFID diagnostic data
Description Register Bit offset Bit length
Channel 0 Channel 1
Overvoltage VAUX 0x0098 0x00AA 7 1
Parameterization error 0x0098 0x00AA 6 1
Configuration via DTM active 0x0098 0x00AA 5 1
Memory full 0x0098 0x00AA 4 1
Read/write head 1 detuned 0x009A 0x00AC 4 1
Read/write head 2 detuned 0x009A 0x00AC 12 1
… … … 0 1
Read/write head 31 detuned 0x00A9 0x00BB 4 1
Read/write head 32 detuned 0x00A9 0x00BB 12 1
Parameter not supported by read/
write head 1.
0x009A 0x00AC 5 1
Parameter not supported by read/
write head 2.
0x009A 0x00AC 13 1
… … … … 1
Parameter not supported by read/
write head 31.
0x00A9 0x00BB 5 1
Parameter not supported by read/
write head 32.
0x00A9 0x00BB 13 1
Read/write head 1 reports error 0x009A 0x00AC 6 1
Error reported by read/write head 2 0x09A 0x00AC 14 1
… … … … 1
Error reported by read/write head 31 0x00A9 0x00BB 6 1
Error reported by read/write head 32 0x00A9 0x00BB 14 1
Expected read/write head 1
not connected
0x009A 0x00AC 7 1
Expected read/write head 2
not connected
0x009A 0x00AC 15 1
… … … … 1
Expected read/write head 31
not connected
0x00A9 0x00BB 7 1
Expected read/write head 32
not connected
0x00A9 0x00BB 15 1
