Commissioning
Connecting the device to a Modbus master with CODESYS
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 52
Digital channels — input data
Description Register Bit offset Bit length
Input value channel 4 0x00BC 4 1
Input value channel 5 0x00BC 5 1
Input value channel 6 0x00BC 6 1
Input value channel 7 0x00BC 7 1
Digital channels — output data
Description Register Bit offset Bit length
Output value channel 4 0x0898 4 1
Output value channel 5 0x0898 5 1
Output value channel 6 0x0898 6 1
Output value channel 7 0x0898 7 1
Digital channels — diagnostic messages
Description Register Bit offset Bit length
Overvoltage at power supply connection
VAUX channel 4/5
0x00BD 2 1
Overvoltage at power supply connection
VAUX channel 6/7
0x00BD 3 1
Overvoltage at output (channel 4) 0x00BD 12 1
Overvoltage at output (channel 5) 0x00BD 13 1
Overvoltage at output (channel 6) 0x00BD 14 1
Overvoltage at output (channel 7) 0x00BD 15 1
Module status — diagnostic messages
Description Register Bit offset Bit length
DTM active in Force mode 0x00BE 14 1
Undervoltage V1 0x00BE 9 1
Undervoltage V2 0x00BE 7 1
Module diagnostics available 0x00BE 0 1
Internal error 0x00BE 10 1
ARGEE program active 0x00BE 1 1
