Commissioning
Connecting the device to an EtherNet/IP scanner using RSLogix
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 72
Digital channels — diagnostic messages
Description Word offset Bit offset Bit length
Overvoltage at power supply connection VAUX channel 4/5 0x00BE 2 1
Overvoltage at power supply connection VAUX channel 6/7 0x00BE 3 1
Overvoltage at output (channel 4) 0x00BE 12 1
Overvoltage at output (channel 5) 0x00BE 13 1
Overvoltage at output (channel 6) 0x00BE 14 1
Overvoltage at output (channel 7) 0x00BE 15 1
Module status — diagnostic messages
Description Word offset Bit offset Bit length
DTM active in Force mode 0 14 1
Undervoltage V1 0 9 1
Undervoltage V2 0 7 1
Module diagnostics available 0 0 1
Internal error 0 10 1
ARGEE program active 0 1 1
