turck TBEN-RFID Series User Manual

Commissioning
Connecting the device to an EtherNet/IP scanner using RSLogix
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 71
DXP channels — parameter data
Description Register Bit offset Bit length
DXP 4 — manual reset of the output after overcurrent 0x0076 0 1
DXP 5 — manual reset of the output after overcurrent 0x0077 0 1
DXP 6 — manual reset of the output after overcurrent 0x0078 0 1
DXP 7 — manual reset of the output after overcurrent 0x0079 0 1
DXP 4 — active output 0x007A 0 1
DXP 5 — active output 0x007B 0 1
DXP 6 — active output 0x007C 0 1
DXP 7 — active output 0x007D 0 1
DXP 4 — advanced digital function 0x007E 0 1
DXP 4 — input filter 0x007E 0 1
DXP 4 — pulse extension (*10ms) 0x007F 0 8
DXP 5 — advanced digital function 0x0082 0 1
DXP 5 — input filter 0x0083 0 1
DXP 5 — pulse extension (*10ms) 0x0084 0 8
DXP 6 — advanced digital function 0x0086 0 1
DXP 6 — input filter 0x0087 0 1
DXP 6 — pulse extension (*10ms) 0x0088 0 8
DXP 7 — advanced digital function 0x008A 0 1
DXP 7 — input filter 0x0139 0 1
DXP 7 — pulse extension (*10ms) 0x008B 0 8
Digital channels — input data
Description Word offset Bit offset Bit length
Input value channel 4 0x00BD 4 1
Input value channel 5 0x00BD 5 1
Input value channel 6 0x00BD 6 1
Input value channel 7 0x00BD 7 1
Digital channels — output data
Description Word offset Bit offset Bit length
Output value channel 4 0x0099 4 1
Output value channel 5 0x0099 5 1
Output value channel 6 0x0099 6 1
Output value channel 7 0x0099 7 1
