turck TBEN-RFID Series User Manual

Commissioning
Connecting the device to an EtherNet/IP scanner using RSLogix
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 70
RFID diagnostic data
Description Register Bit offset Bit length
Channel 0 Channel 1
Overvoltage VAUX 0x0099 0x00AB 7 1
Parameterization error 0x0099 0x00AB 6 1
Configuration via DTM active 0x0099 0x00AB 4 1
Buffer full 0x0099 0x00AB 4 1
Read/write head 1 detuned 0x009B 0x00AD 4 1
Read/write head 2 detuned 0x009B 0x00AD 12 1
… … … 0 1
Read/write head 31 detuned 0x00AA 0x00BC 4 1
Read/write head 32 detuned 0x00AA 0x00BC 12 1
Parameter not supported by read/
write head 1.
0x009B 0x00AD 5 1
Parameter not supported by read/
write head 2.
0x009B 0x00AD 13 1
… … … … 1
Parameter not supported by read/
write head 31.
0x00AA 0x00BC 5 1
Parameter not supported by read/
write head 32.
0x00AA 0x00BC 13 1
Read/write head 1 reports error 0x009B 0x00AD 6 1
Error reported by read/write head 2 0x009B 0x00AD 14 1
… … … … 1
Error reported by read/write head 31 0x00AA 0x00BC 6 1
Error reported by read/write head 32 0x00AA 0x00BC 14 1
Expected read/write head 1
not connected
0x009B 0x00AD 7 1
Expected read/write head 2
not connected
0x009B 0x00AD 15 1
… … … … 1
Expected read/write head 31
not connected
0x00AA 0x00BC 7 1
Expected read/write head 32
not connected
0x00AA 0x00BC 15 1
