578
Model
No Page
1012.08.1998 6000---8750 39.18
FIELDMASTER, fitting instruction
(10)
Drill
Sensor Wire color Plug pin
RPM sensor on drill shaft
(
2
w
i
r
e
s
)
blue 1
(2 wires)
brown 5
RPM sensor on drill shaft
(
3
w
i
r
e
s
)
blue 6
(3 wires)
brown 5
black 1
RPM semsor on switch blue 2
brown 5
Drill boot sensor sininen 6
ruskea 5
musta 4
Implement sensor sininen 7
ruskea 5
Baler
Sensor Wire color Plug pin
Piece counter blue 1
brown 5
RPM semsor 3 or weight module blue 6
brown 5
black 2
RPM sensor 2 blue 6
brown 5
black 4
RPM sensor 1 blue 6
brown 5
black 7
Slurry spreader
Sensor Wire color Plug pin
RPM sensor 1 blue 6
brown 5
black 1
Flow meter +12 V 6
0V 5
Signal 2
Wheel sensor blue 4
brown 5
Implement sensor blue 7
brown 5
