1-16 Instrument Description
During a sample run, an event output can be configured to actuate between
acquisitions and is used typically to enable an external device to start at the
same time the acquisition starts.
See also: Figure titled “Analog Inputs, Contact Closure Inputs, and Contact
Closure Event Out outputs:” on page 1-14.
SIP, fiber-optic and power inlet connections:
ESD Earth
For engineers’ use only.
SIP
Scan-in-progress connection to the EPC.
See also: Figure titled “GCT Premier system external wiring:” on page D-3.
Power
Power switch
SIP
Fiber-optic
connections
Power fuse
ESD Earth
