Weber Alpha HSM User Manual

Chapter 1 General 40058725 BTA Alpha HSM
Version: 12.19.17 Page 11 of 112 GB
Technical term
Explanation
Dispensing tamp (tamp)
Unit that picks the label through vacuum, transports it to the
product and places it there
Dispensing tamp (tamp)
Unit that picks the label through vacuum, transports it to the
product and applies it there.
Display
Display panel where the status information is shown to the
operator.
Display controller
Control unit with an integrated display field for information
(see "display") and keypad for the operation and program-
ming.
Donation (Applicator)
Designation for the application unit.
Edge detection
(Edge detection)
The edge (front or rear) of a product or a label is used by the
sensor for the detection of the product or respectively the
label gap.
Factory setting
Includes all basic factory settings of the system which, how-
ever, may differ from the state after commissioning the sys-
tem. Software parameters are reset by resetting to the factory
settings (default values) and the previously adjusted values
will be lost.
Feed
See "Label feed".
HMI
Abbreviation for Human-Machine-Interface (user interface).
Input device for the labeling systems or for controlling the
components.
Home Position
Basic position of the tamp at the peel bar.
Home position sensor
Sensor to acquire the end position, when the dispensing tamp
is in the home position.
Hotline
Telephone support of the customer for a rapid diagnosis.
Input mode
Mode in which a numeric value in the display can be set
higher or lower.
Label applicator
See “Labeler”.
Label end warning signal
(Label out)
An optical sensor (diffuse reflection light scanner) which is
used to detect the label end.
Label feed
(Label Feed)
The feeding of a label. Pressing the [Start] button activates
the drive unit motor and starts label web transport. The ad-
vanced label is removed from the backing paper on the peeler
plate.
Label Gap
Spacing between two labels on the label liner. The gap is
detected by the applicator via a (label) sensor.
Label gap sensor
See “Label sensor”.
Label Sensor
See “Label sensor”.
Label sensor (Label Sensor)
An optical sensor which detects the gap between labels.
Label size
Specifies the label format: Width x length (in the travel direc-
tion of the label liner). It is measured in millimetres [mm].
Label web
Silicon-coated backing tape on which individual labels are
stuck.
