Chapter 8 Operation 40058725 BTA Alpha HSM
Version: 12.19.17 Page 91 of 112 GB
Metric / Imperial
Here you can set the measurement units ("met-
rical" or "imperial") of the labeling system.
Fig. 8-62: Measuring unit system
Machine parameters
Incorrect parametrisation can lead to process and function errors
that can also cause mechanical damage. This also applies for
changes to reserved or undocumented parameters, as well as
parametrization which is beyond the valid parameter range.
- The parametrisation may only be conducted by trained persons!
The menu pages "Unwind" and "Wind" are only displayed for mod-
ules with servo drive.
From the menu pages "Machine parameters”,”Unwinder" and “Rewinder" you can access
the submenus by pressing the setting knob briefly, which include all machine parameters
of the labeler.
Password authentication is in place, to protect the system settings.
After a correct password entry, access to the system parameters is permitted, which as-
sumes the user possesses in-depth knowledge thereof.
Most parameters remain unchanged in their factory settings for normal applications. Some
parameters may need to be adapted to specific requirements (usually once during the in-
stallation).
Fig. 8-63: Machine parameters
