Chapter 6 Installation and connection 40058725 BTA Alpha HSM
Version: 12.19.17 Page 36 of 112 GB
Installation
Only an optimally aligned system installation is able to ensure trouble-free continuous op-
eration with minimal wear. For optimal system installation, it is essential to carry out fine-
tuning that is adapted to the application conditions. Fine-tuning requires an extensive ex-
pertise which is primarily founded on experience gained from working in the field of label-
ing technology.
Since this specific expertise can not be fully conveyed by the operating instructions, it is
required that the installation of the labeler is performed by a Bluhm Weber Group techni-
cian, or an approval is issued through a final inspection. Damage or consequential dam-
age which is attributable to improper installation without the necessary fine-tuning, shall
not be covered by the warranty.
Requirements regarding the installation location
Closed and clean room.
Flat, solid base, roughness may not exceed 5 mm when using bases from the
Bluhm Weber Group.
Sufficient floor load-bearing capacity
Low-vibration environment.
Adequate lighting: 500 Lx.
No direct irradiation by sunlight or radiators.
The labeler may not be operated in the vicinity of electrostatic or magnetic fields.
This can cause controller faults.
Correct energy supply (electricity, compressed air if necessary) according to the
chapter "Technical data".
Positioning of the labeler
The labeler may not come into contact with the product.
The installation location must allow sufficient access for the operators and service
technicians. Especially the power switch/plug to disconnect the mains voltage must
be easily accessible.
Make sure that all fasteners are sufficiently tightly secured.
Observe all the points of the “Intended use" in the "Safety Regulations" chapter on
page 15.
