Chapter 10 Troubleshooting 40058725 BTA Alpha HSM
Version: 12.19.17 Page 104 of 112 GB
Correct the settings after the labeling result
Based on the labeling result, it is possible to draw conclusions regarding the necessary
settings.
Proper labeling
If the labeling is performed correctly, the label will be
 wrinkle-free,
 straight,
 always at the same position on the product.
No correction will be necessary.
Fig. 10-1: Product with the proper labeling results
Error during the labeling
The label has wrinkles.
Fig. 10-2: Product with wrinkles in the label
The labeling result must be corrected as follows:
Step
Approach
1
The application speed of label could be too high. Check and correct dispens-
ing speed.
