Weber Alpha HSM User Manual

Chapter 8 Operation 40058725 BTA Alpha HSM
Version: 12.19.17 Page 85 of 112 GB
Pre Feed
The pre feed position is a value that ensures that a
label is pre-dispensed to a defined position by us-
ing the "Trigger 2" (optional) input before it is finally
applied to the product using the regular product
detector.
The adjustment range is 0.0 – 900.0 mm.
Fig. 8-39: Pre Feed
The display of the "Pre Feed" parameter in the configuration menu can be activated
or deactivated by using the 041 "Pre-feed configuration" machine parameter in the sys-
tem menu.
Parameter list configuration
All parameters of the configuration menu can be entered here.
Product / batch >
Parameter
Speed [m/min]
Trigger delay [mm]
Label position [mm]
Label Length [m]
Label Gap [mm]
Labels Burst
Label Distance [mm]
Label skip
Trigger Blank [mm]
Ramp [mm]
Stop ramp [%]
Speed Control
Sync Start [mm]
Sync Length [mm]
Pre Feed [mm]
Pre Feed
