Weber Alpha HSM User Manual

Chapter 9 Maintenance and repair 40058725 BTA Alpha HSM
Version: 12.19.17 Page 99 of 112 GB
Empty the water separator of the compressed air supply
Damage caused by condensation water
Condensation water can penetrate into the pneumatic system
and damage the pneumatic components.
- Check and if necessary drain the water trap regularly.
Fig. 9-2: Maintenance unit (filter-regulator-pressure gauge combination)
No.
Designations
1
COUPLING PLUG
2
SLIDE PLATE
3
CONTROL KNOB
4
COMPRESSED AIR PRESSURE GAUGE
5
COLLECTING TANK
6
DRAIN VALVE
7
FILTER ELEMENT
Prerequisites
 labeling machine is separated from the voltage and compressed air
 No product handling.
