Chapter 4 Description of the labeler 40058725 BTA Alpha HSM
Version: 12.19.17 Page 27 of 112 GB
General overview
The labeler shown here is a configuration example and can deviate from the version supplied
(see also Module overview, page 28).
Fig. 4-1:Alpha HSM-LH in the front view
Module for receiving and unwinding of label rolls
Keeps the label material evenly tensioned and regulates the unwinding speed.
Fixing the label roll on the clamping axle.
Basic module with drive, control and connections.
Moves the label material forward.
Presses the pressure roller against the drive roller.
Adjusts the material tension to optimize peeling behaviour of the labels.
