Technical Description: Ink System Operation
Issue 2
97
Part No. 306-0430-102
Ink Addition to Mixer Tank
When the level of fluid in the mixer tank falls below the level OK sensor, the ink top up valve V2 is energised.
Ink from the reservoir flows round the system into the mixer tank until the level OK sensor is covered. V2 is then
de-energised (Figure 49).
NOZZLE
FILTER
PRE HEAD FILTER
GUTTER
Figure 49 Ink Addition to Mixer Tank
