WILLETT 430 - Installation

430 Ink Jet Printer Service and Maintenance Manual
124
Issue 2
Part No. 306-0430-102
9
Withdraw the pump and its sealing gasket. Discard the gasket.
Installation
1
Ensure that the pump is the correct type for the machine.
2
Place the pump in position, with a new sealing gasket fitted between the pump and the bulkhead. Ensure
that the pump orientation is correct.
3
Secure the pump to the bulkhead, using the two screws retained at
Removal
step
8
.
4
Connect the ink feed (
4
) and outlet pipes to the pump.
5
Connect the top of the ink feed pipe to the T connector (
1
) next to V1 (Top up valve). Remove the tissue or
cloth (placed to catch ink spillage) from beneath the pump.
6
Put the baffle plate in position and secure it with the two screws (
2
) retained at
Removal
step
3
.
7
Connect the PUMP connector (
3
) to the I/O board.
