WILLETT 430 - Major Sub-Assemblies

430 Ink Jet Printer Service and Maintenance Manual
170
Issue 2
Part No. 306-0430-102
Major Sub-Assemblies
1
2
3
4
5
Figure 85 Major Sub-Assemblies
Fig ref. Description Qty Remarks
Top moulding ink system components - See Figure 861
Top moulding, keypad and LCD See Figure 87
2 Baffle plate assembly 1 See Figure 88
3 Printhead assembly 1 See Figure 89
Base moulding and cabinet 1 See Figure 904
Mains plate assembly 1 See Figure 91
5 Ink system 1 See Figure 92
Table 51 Major Sub-Assemblies
