Earlier 430 Model
This appendix is to be used as reference to the earlier version of the 430 si printer.
The earlier version of the 430 si printer incorporated a flush reservoir/tank, which has been removed and
superseded by a pre pump filter.
Ink System
General
1
16
15
14
13
2
3
4
5
6
7
11
12
8
9
10
(
1
) Ink reservoir manifold (
7
)FMS (
13
) Top up reservoir
(
2
) Top up reservoir manifold (
8
) Pressure transducer housing (
14
) Ink reservoir
(
3
) Solenoid valve V6 (Ink) (
9
) Mixer tank (
15
) Flush pump
(
4
) Solenoid valve V8 (Gutter) (
10
) Ink system pump (
16
) Solenoid valve V1 (Top Up Addition valve)
(
5
) Solenoid valve V3 (VMS) (
11
) Flush reservoir (
17
) Solenoid valve V2 (Ink Addition valve)
(
6
) Solenoid valve V7 (Flush
pump)
(
12
) Main filter
Figure 93 Earlier 430 Ink System Components
