WILLETT 430 - Installation; Mains Switch; Removal

430 Ink Jet Printer Service and Maintenance Manual
120
Issue 2
Part No. 306-0430-102
Installation
1
Refit the cables, removed at
Removal
step
2
, to the terminals on the rear of the inlet connector
(Figure 57 (
4
)).
2
Fit the inlet connector to the connector panel (
1
) and secure it with the screws (
5
), nuts and washers (
6
)
removed at
Removal
step
1
.
Mains Switch
Removal
1
Remove the cables from the terminals at the rear of the mains switch (Figure 57 (
2
)) noting their position for
Installation.
2
Remove the cover (
3
) from the mains switch.
3
Push the switch out of its mounting hole, noting the orientation for installation.
Installation
1
Push the mains switch (
2
) into its mounting hole after first checking that the orientation is correct.
2
Fit the cover (
3
) to the switch.
3
Reconnect the cables, removed at
Removal
step
1
, to the terminals at the rear of the switch.
