430 Ink Jet Printer Service and Maintenance Manual
118
Issue 2
Part No. 306-0430-102
5
Place the new sensor and LED in the sensor holder (
4
).
6
Thread the new sensor and LED leads through the spacer tube.
7
Reinsert the O-ring, lens, sensor holder and spacer into the level detect retainer.
8
Replace the lens retainer. Do not over-tighten.
9
Install the assembled level detector as described above.
