430 Ink Jet Printer Service and Maintenance Manual
176
Issue 2
Part No. 306-0430-102
Fig ref. Part number Description Qty Remarks
Fig 83 Printhead assembly
1 100-0370-196 Front cover 1
2 100-0370-231 Lid switch thumbscrew 2
3 200-3900-135 Charge electrode/LED assy. 1
4 200-0430-141 Nozzle assembly 1
5 200-0390-235 Cover switch assy. 2
6 200-0430-262 Head heater assy. 1
7 521-0001-167 Pico valve 1
8 500-0031-180 O-ring 25.81 x 3.53 CS 1
9 500-0011-121 M2 5 x 6 Csk hd St. St. Screw 2
10 200-0430-208 Umbilical 1
11 100-0370-195 Rear cover 1
12 200-3900-298 Phase detector assy. 1
13 200-0430-131 EHT block assy. 1
14 100-0470-273 0 V plate 1
15 100-0430-115 Last chance filter 1
16 500-0122-125 Spring 1
Table 55 Printhead
