430 Ink Jet Printer Service and Maintenance Manual
178
Issue 2
Part No. 306-0430-102
Fig ref. Part number Description Qty Remarks
1 500-0048-117 ¼ turn fastener 3
2 500-0049-101 ¼ turn retainer 6
3 500-0048-119 ¼ turn receptacle 3
4 100-0370-127 Outer cover 2
5 400-0009-145 Rating label 1
6 400-0009-132 CE label 1
7 400-0009-295 Outlet label 1
8 500-0067-116 High voltage warning label 1
9 500-0048-118 ¼ turn fastener 3
10 500-0036-429 EHT module blank jack 1
11 500-0031-187 Seal 2
12 200-0390-239 EHT module 1
13 100-0430-137 Main harness 1
14 - Mains plate assy. 1 See Figure 91 Mains Plate Assembly.
15 200-0390-260 Base moulding assy. 1
16 500-0901-135 80 x 80 fan 1
17 500-0901-121 Fan filter assy. 1
18 500-0901-122 Fan filter element 1 Contains finger guard, filter cover and filter element
19 500-0901-126 Metallic filter gauze 1
20 100-0370-190 Seal 1
21 430 Badge 1
22 Willett logo badge 1
NI 100-0370-139 Power cable assembly 1
Table 56 Base Moulding and Cabinet
