430 Ink Jet Printer Service and Maintenance Manual
180
Issue 2
Part No. 306-0430-102
Fig ref. Part number Description Qty
1 100-0370-141 RS485/product sensor cable assembly 1
2 100-0370-143 Shaft encoder cable assembly 1
3 100-0370-142 RS232 cable assembly (optional) 1
4 500-0076-133 Blanking plug 6
5 500-0082-145 Mains switch 1
6 500-0082-120 Mains switch cover 1
7 500-0066-134 Fuse holder 2
8 500-0066-139 3.15 A HRC A/S fuses
5 A HRC A/S fuses
2
2
9 500-0097-117 Mains inlet IEC filter 1
10 500-0079-110 Fuse holder boot 2
NI 100-0370-206 Mains boot gasket 1
NI 500-0043-101 Mains cable 1
Table 57 Mains Plate Assembly
