430 Ink Jet Printer Service and Maintenance Manual
182
Issue 2
Part No. 306-0430-102
Fig ref. Part number Description Qty Remarks
1 527-0001-125 Pressure transducer 1
2 500-0031-164 Pressure transducer front O-ring 1
3 521-0001-168 Feed valve (hex) 6
4 200-0430-144 FMS single head ink system 1
5 200-0390-115 Level detect assembly 2 Contains; detector retainer, O-ring,
lens, sensor holder, spacer table
and lens retainer
6 500-0031-164 Level detect seal 2
7 100-0370-106 Solvent/ink tank 2
8 200-0390-108 Pump assembly 1
9 100-0370-111 Pump sealing gasket 1
10 200-0390-119 Fan failure PCB assembly 1
11 500-0047-122 Main filter 1
12 100-0370-202 Solvent tank manifold 1
13 100-0370-212 Manifold gasket 2
14 500-0010-451 M5 x 6 nylon screw 2
15 100-0370-203 Ink manifold 1
16 500-0008-152 M5 x 20 cap head screws 8
17 500-0031-201 Pressure transducer rear O-ring 1
18 100-0370-200 Pressure transducer manifold 1
19 200-0430-146 Flush pump assembly 1
NI 204-0212-101 FMS level sensor assembly 1 Contains, O-ring, lens, sensor holder
and lens retainer
NI 100-0390-134 Venturi assembly 1
NI 100-0370-112 Printhead fluid connector 1
NI 500-0031-175 4.78 x 1.78 O-ring 1
NI 500-0031-117 1.78 x 1.78 O-ring
NI 500-0041-265 A1 barb 3 Fitted to feed valves (3)
NI 500-0022-213 A1 barb sealing washer 1
NI 100-0370-102 VMS restrictor block 1
NI 500-0031-165 VMS restrictor
O-ring, 12.1 x 1.6 mm
1
NI 100-0370-179 Level sense kit 1 Contains; 5 pairs IR emitter/receiver
devices with colour coded flying
leads fitted
Table 58 Ink System
