430 Ink Jet Printer Service and Maintenance Manual
12
Issue 2
Part No. 306-0430-102
1
3
2
3
2
(
1
) Input/Output board (
2
) Sensor 2/Quadrature shaft encoder jumper JB2 (
3
) Print trigger 1 and 2 jumper JB1
Figure 7 Input/Output Board Product Sensor and Shaft Encoder Jumper Location
