430 Ink Jet Printer Service and Maintenance Manual
36
Issue 2
Part No. 306-0430-102
NOZZLE
GOODLOW
LIGAMENT
LIGAMENT
VERY LOW HIGH VERY HIGH
CHARGE
ELECTRODE
CHARGE
ELECTRODE
SATELLITE
SATELLITE
Figure 16 Inkjet Break-off Point
12
When a good break-off point is achieved, press
enter
. Enable the Rolling Phase:
13
From the
System
menu select
Rolling Phase Disable
and
press
enter
.
14
Toggle to
Enable
then press
enter
.
