430 Ink Jet Printer Service and Maintenance Manual
58
Issue 2
Part No. 306-0430-102
Connectors
The CPU board connectors shown in Figure 24. Pinout details are given in the tables below.
1234
5
6
7
9
8
(
1
) CON_K (
4
) CON_S (
7
) CON_L
(
2
) CON_232 (
5
) CON_P (Interboard connector) (
8
) Link W3
(
3
) CON_B (Interboard connector) (
6
) CON_D (Interboard connector) (
9
) CON_LAN
Figure 24 CPU Board Connectors
