ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S4
ENGINE KEY SWITCH SHUT-OFF SYSTEM
4WD
OPC
Coolant Temperature
Indicator Does Not
Light When Water
Temperature Gauge
Points to H (Red
Zone)
Fuse blown Replace 8-S10,
8-S11
Coolant temperature sensor is damaged Replace 8-S40
Wiring harness disconnected or improperly
connected (between panel and coolant
temperature sensor)
Repair or replace –
Circuit in panel board is damaged Replace 8-M28
4WD Indicator Lamp
Lights Up When 4WD
Is Not Engaged
4WD switch is damaged Replace 8-S52
4WD Indicator Lamp
Does Not Light When
4WD Is Engaged
4WD switch is damaged Replace 8-S52
Symptom Probable Cause Solution
Reference
Page
Engine Does Not
Stop When Main
Switch Is Turned OFF
Fuse blown Replace 8-S10,
8-S11
Meter panel damaged Replace 8-M28
Wiring harness disconnected or improperly
connected
Repair or replace –
Engine Does Not
Start
Fuse or slow blow fuse blown Replace 8-S10
PTO switch damaged Replace 8-S55
Shuttle neutral switch damaged Replace 8-S35
Symptom Probable Cause Solution
Reference
Page
Front Wheel Does
Not Drive When 4WD
Switch is Turned ON
4WD switch or wiring harness is damaged Replace 8-S52
Front Wheel Drive
Not Be Cancelled
4WD switch or wiring harness is damaged Repair or replace 8-S52
Symptom Probable Cause Solution
Reference
Page
Buzzer Does Not
Buzz
Fuse blown Replace 8-S10,
8-S11
Buzzer damaged Replace 8-S54
Seat switch damaged Replace 8-S53
Wiring harness disconnected or improperly
connected
Repair or replace –
Symptom Probable Cause Solution
Reference
Page
To Next Page
