ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S5
GAUGES
LCD MONITOR
9Y1210828ELS0001US0
Symptom Probable Cause Solution
Reference
Page
Fuel Gauge Does Not
Function
Fuel level sensor damaged Replace 8-S37
Wiring harness disconnected or improperly
connected (between meter panel and fuel unit)
Repair or replace –
Circuit in meter panel damaged Replace 8-M28
Coolant Temperature
Gauge Does Not
Function
Coolant temperature gauge damaged Replace 8-M28
Coolant temperature sensor damaged Replace 8-S40
Wiring harness disconnected or improperly
connected (between meter panel and coolant
temperature sensor)
Repair or replace –
Circuit in meter panel damaged Replace 8-M28
Symptom Probable Cause Solution
Reference
Page
Nothing is Displayed
in LCD
Battery discharged or damaged (Battery voltage
is below 10 V)
Recharge or replace G-25,
8-S8
Slow blow fuse blown Replace 8-S10,
8-S12
Meter panel connector disconnect Connect 8-M28
Meter panel damaged Replace 8-M28
Indication on LCD
Does Not Change
When Pushing the
Display Mode Switch
Display mode select switch damaged Replace 8-S22
Wiring harness disconnected Repair –
Traveling Speed is
Not Indicating
Wiring harness disconnected Repair –
Traveling speed sensor damaged Replace 8-S38
PTO Speed in Not
Indicating
Wiring harness disconnected Repair –
KiSC issued 08, 2013 A
