Xiotech—Proprietary 160337-000 Rev D, 30 September, 2013 Page 109
Monitoring ISE User Guide
If the ISE is subscribing to warning or critical overtemperature events as SNMP traps, notifications are sent to
the destinations specified (see “SNMP Setup” on page 53) as shown in Table 31.
Table 31: Web-Mgt Interface Temperature Events
Event Summary
Below the temperature indicator is the
Event Summary
section, where events recorded by the ISE are listed.
Environment
Select
Environment
>>
display
to view the environment summary of all components in the ISE and the overall
storage pool status. To view detailed information for any component, click
just to the left of the component.
Click
Refresh
or press
F5
to update the environment status.
Figure 79. Overall System Environment Page (Part 1)
The
MRC
section of the
Environment
page includes the following information (Figure 79):
•Status
Temperature Event Current Temperature Bar SNMP Trap
Exceeds warning threshold
Yellow range turns bright yellow
FRU - Warning Temperature Threshold
Exceeds critical threshold
Red range turns bright red
FRU - Critical Temperature Threshold
Returns to operational range
Green range turns bright green
FRU - Temperature Back to Normal
