Xerox WorkCentre 3550 - Safety

April 2010
6-38
Phaser 3635MFP/WorkCentre 3550
dC131
General Procedures/Information
07-140 Top Registration
Tray 1 Duplex
(1st sid)e
The changed dimension of tray
1 top registration of 1st side in
duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-150 Side Registration
Tray 1 Duplex
(1st sid)e
The changed dimension of tray
1 side registration of 1st side in
duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-200 Top Registration
Tray 2 Simplex
The changed dimension of tray
2 top registration in simplex.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-210 Side Registration
Tray 2 Simplex
The changed dimension of tray
2 side registration in simplex.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-220 Top Registration
Tray 2 Dup_long
(2nd sid)e
The changed dimension of tray
2 top registration of 2nd side in
duplex long.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-230 Side Registration
Tray 2 Dup_long
(2nd sid)e
The changed dimension of tray
2 side registration of 2nd side
in duplex long.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-240 Top Registration
Tray 2 Duplex
(1st sid)e
The changed dimension of tray
2 top registration of 1st side in
duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-250 Side Registration
Tray 2 Duplex
(1st sid)e
The changed dimension of tray
2 side registration of 1st side in
duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-500 Top Registration
Bypass Simplex
The changed dimension of
bypass top registration in sim
-
plex.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-510 Side Registration
Bypass Simplex
The changed dimension of
bypass side registration in sim
-
plex.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-520 Top Registration
Bypass Dup_long
(2nd sid)e
The changed dimension of
bypass top registration of 2nd
side in duplex long.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-530 Side Registration
Bypass Dup_long
(2nd sid)e
The changed dimension of
bypass side registration of 2nd
side in duplex long.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-540 Top Registration
Bypass Duplex
(1st sid)e
The changed dimension of
bypass top registration of 1st
side in duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
07-550 Side Registration
Bypass Duplex
(1st sid)e
The changed dimension of
bypass side registration of 1st
side in duplex long and short.
0mm to 6mm
(13 steps /
0.5mm seg.)
3
Table 7 NVM chain 7
Location NVM Name NVM Description Value Default
Table 8 NVM chain 9
Location NVM Name NVM Description Value Default
09-100 LD Light Level 600dpi laser light level. Value
in PWM.
200 to 600 350
09-110 MHV Control Bias
Control
Main charge bias control.
Basic of value (HVPS setting is
valu)e. Value in PWM.
108 to 145 126
09-120 THV Bias Control
Control
Transfer bias control. Basic of
value (HVPS setting is valu)e.
Value in PWM.
41 to 220 76
09-130 Deve Bias Control DEVE bias control. Basic of
value (HVPS setting is valu)e.
Value in PWM standard volt
-
age: --500V (PWM 522).
408 to 607 522
09-140 Detach Bias Con-
trol
Detack bias control. Basic of
value (HVPS setting is valu)e.
Value in PWM standard volt
-
age: -1800V.
80 to 160 123
09-205 Print Cartridge
Life Page Counter
Display of print cartridge pages
count.
(Read only)
09-230 Transfer Roller
Life Page Counter
Display value of pages count. (Read only)
Table 9 NVM chain 10
Location NVM Name NVM Description Value Default
10-200 Fuser Life Page
Counter
(Read only) Total fuser page
count
10-210 Heat Roll Life
Page Counter
(Read only) Heat roll page
count
10-220 Pressure Roll Life
Page Counter
(Read only) Pressure roll page
count
10-300 Pick-up Interval
Delay
Change the time interval for
paper pick-up.
0 to 100 msec. 0
10-310 Pick-up Interval
Delay (Special
Paper)
Change the time interval for
paper pick-up.
0 to 100 msec. 0
Table 10 NVM chain 20
Location NVM Name NVM Description Value Default
20-100 Redial Attempts Number of times to
redial.
1 to 13 3
20-110 Redial Interval Time between each
redial.
1 to 15 2
20-200 Pause Dial Time Time of each pause. 0 to 200 (1000 msec.) 1
20-210 Dial Pulse M/B
Ratio
Dial pulse make/break
ratio.
33/66 (0)
40/60 (1)
1
