Xinje XD Series User Manual

306
system
S3+38
Last sampling
temperature
-32767~32767
Internal usage
parameters of the
system
S3+39
The time from auto-
tuning PID operation to
inflection point
-32767~32767 (unit: ms)
Internal usage
parameters of the
system
S3+40
Starting sampling value
of auto-tuning PID
operation
-32767~32767
Internal usage
parameters of the
system
S3+41
Number of times at
inflection point during
auto-tuning
0~65535
Internal usage
parameters of the
system
S3+42
Useless time
0~4294967296 (unit: ms)
Internal usage
parameters of the
system
S3+44
Stop temperature
Temperature at the end of auto-
tuning
Range:-32767~32767
Internal usage
parameters of the
system
Critical oscillation part (read only parameters, only for monitoring)
S3+24
PID control mode
0: PID control
1: PI control
2: P control
16-bit no sign,
internal usage
parameters of the
system
S3+25
Current auto-tuning
segment
0: Preparation stage
1: start to auto tune
2~3: auto-tuning parameter
collection
4: calculation of PID parameters
16-bit no sign,
internal usage
parameters of the
system
S3+26
The auto-tuning
temperature is located
at the number of peaks
0: first peak
1: second peak
16-bit no sign,
internal usage
parameters of the
system
S3+27
The lowest sampling
temperature
-32767~32767
Internal usage
parameters of the
system
S3+28
The highest sampling
temperature
-32767~32767
Internal usage
parameters of the
system
S3+30
sampling time of the
lowest sampling
temperature
0~4294967296 (unit: ms)
Internal usage
parameters of the
system
S3+32
sampling time of the
highest sampling
temperature
0~4294967296 (unit: ms)
Internal usage
parameters of the
system
S3+34
auto-tuning time
cumulative
0~4294967296 (unit: ms)
Internal usage
parameters of the
system
Manual control part (read only parameters, only for monitoring)
S3+24
current target
temperature
-32767~32767
Internal usage
parameters of the
system
S3+25
Need to update target
temperature
0: no need
1: need
16-bit no sign,
internal usage
