Xinje XD Series User Manual

379
3)Suitable Soft Components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S1
●
●
●
●
●
S2
●
●
●
●
●
D
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM；S includes S,HS；T
includes T,HT；C includes C, HC.
PWM K100 D10 Y0
X0
S1·
S2·
D·
Duty cycle n: 1~65535.
Output pulse f: 1~100KHz
XD series PLC PWM output need transistor type terminal:
PLC model
PWM terminal
XD2-16T/RT -24T/RT -32T/RT -48T/RT -60T/RT
Y0、Y1
XD3-16T/RT -24T/RT -32T/RT -48T/RT -60T/RT
Y0
、
Y1
XD5-16T/RT -24T/RT -32T/RT -48T/RT -60T/RT
Y0、Y1
XD5-24T4 -32T4 -48T6 -60T6-60T10
Y0、Y1、Y2、Y3
XD5-24D2T2
Y0
、
Y2
、
Y4
、
Y6
XD5-48D4T4
Y14
、
Y16
XDM-24T4 -32T4 -60T4 -60T10
Y0
、
Y1
、
Y2
、
Y3
XDC-24T -32T -48T -60T
Y0
、
Y1
XD5E-30T -60T
Y0
、
Y1
XD5E-30T4 -60T4 -60T6 -60T10
Y0
、
Y1
、
Y2
、
Y3
XDME-30T4 -60T4 -60T10
Y0
、
Y1
、
Y2
、
Y3
XL3-16T/32T
Y0、Y1
XL5-16T/32T
Y0
、
Y1
XL5E-16T/32T
Y0
、
Y1
XL5-32T4, XL5E-32T4/64T6, XLME-32T4
Y0、Y1、Y2、Y3
XL5-64T10, XL5E-64T10,XLME-64T10
Y0、Y1、Y2、Y3
Function and Action
