436
Address
Function
Note
Serial
port 0
SM140
Modbus instruction execution
flag
When the instruction starts to
execute, set ON
When execution is complete, set
OFF
SM141
X-NET instruction execution
flag
When the instruction starts to
execute, set ON
When execution is complete, set
OFF
SM142
Free format communication
sending flag
When the instruction starts to
execute, set ON
When execution is complete, set
OFF
SM143
Free format communication
receive complete flag
When receiving a frame of data
or receiving data timeout, set
ON.
Require user program to set OFF
Serial
port 1
SM150
Modbus instruction execution
flag
Same to SM140
SM151
X-NET instruction execution
flag
Same to SM141
SM152
Free format communication
sending flag
Same to SM142
SM153
Free format communication
receive complete flag
Same to SM143
Serial
port 2
SM160
Modbus instruction execution
flag
Same to SM140
SM161
X-NET instruction execution
flag
Same to SM141
SM162
Free format communication
sending flag
Same to SM142
SM163
Free format communication
receive complete flag
Same to SM143
Serial
port 3
SM170
Modbus instruction execution
flag
Same to SM140
SM171
X-NET instruction execution
flag
Same to SM141
SM172
Free format communication
sending flag
Same to SM142
SM173
Free format communication
receive complete flag
Same to SM143
Serial
port 4
SM180
Modbus instruction execution
flag
Same to SM140
SM181
X-NET instruction execution
flag
Same to SM141
SM182
Free format communication
sending flag
Same to SM142
SM183
Free format communication
receive complete flag
Same to SM143
Serial
SM190
Modbus instruction execution
flag
Same to SM140
Communication(SM140-SM193)
