Yamaha F150B - Canister

6-6
Canister
0
1
2
3
4
5
6
7
8
9
10
A
Canister
No. Part name Q’ty Remarks
1Hose 1
2 Plastic tie 7
Not reusable
3 Joint 1
4Hose 1
5 Clamp 1
6Hose 1
7Bolt 1 M6 × 16 mm
8 Filter 1
9 Bracket 1
10 Canister 1
11 Bolt 1 M6 × 42 mm
12 Grommet 3
13 Collar 3
14 Bolt 2 M6 × 30 mm
15 Bracket 1
16 Hose 1
17 Hose 1
1
3
11
12
13
12
13
14
2
16
2
2
4
5
26
7
89
10
2
2
17
10 N m (1.0 kgf m, 7.4 ft lb)
12
13
15
Fuel line / Canister
