8-53
LOWR
Lower unit
Propeller shaft housing (counter rotation model)
No. Part name Q’ty Remarks
1 Self-locking nut 1
2 Water inlet cover (STBD) 1
3 Shift rod joint 1
4Ball 2
5 Shift slider 1
6Ball 2
7Ball 2
8Spring 1
9 Forward gear 1
10 Thrust washer 1
11 Taper roller bearing 1
Not reusable
12 Shim (T2) —
13 Cross pin 1
14 Dog clutch 1
15 Spring 1
16 Screw 1 M5 × 54 mm
17 Water inlet cover (PORT) 1
3
5
4
7
6
13
27
8
6
7
4
14
15
5 N m (0.5 kgf m, 3.7 ft lb)
143 N m (14.3 kgf m, 105.5 ft lb)
1
2
3
4
6
7
14
25
18
26
27
24
23
22
21
20
19
13
12
9
10
11
8
15
4
16
17
6
5
