Yamaha F150B - PTT Unit

9-32
PTT unit
0
1
2
3
4
5
6
7
8
9
10
A
PTT unit
No. Part name Q’ty Remarks
1Shaft 1
2 Circlip 1
3 Bushing 6
4 PTT unit 1
5 Ground lead 1
6Bolt 1 M6 × 10 mm
7 Bolt 2 M10 × 30 mm
8 Washer 2
9Shaft 1
10 Plastic tie 3
Not reusable
1
2
3
3
3
3
4
5
6
7
8
9
10
7
8
39 N m (3.9 kgf m, 28.8 ft lb)
Clamp bracket and swivel bracket / PTT unit
