Yamaha F150B - Removing the Propeller Shaft Housing Assembly; Disassembling the Propeller Shaft Housing Assembly

8-55
LOWR
Lower unit
Removing the propeller shaft
housing assembly
1. Fold one tooth of the claw washer that is
bent toward the propeller.
2. Loosen the ring nut.
3. Remove the ring nut c and claw washer
d.
4. Remove the propeller shaft housing
assembly, and shim(s) (T2).
TIP:
Be careful not to lose the key g.
Disassembling the propeller shaft
housing assembly
1. Remove the spring a, and then remove
the cross pin b, shift rod joint c, dog
clutch d, balls e, f, g, spring h, and
shift slider i.
Ring nut wrench 4 a: 90890-06512
Ring nut wrench extension b:
90890-06513
a
b
d
c
Slide hammer e: 90890-06531
Puller head f: 90890-06514
e
f
g
a
b
d
e
h
c
i
g
g
f
f
