Yamaha F150B - Exhaust Cover

7-32
Exhaust cover
0
1
2
3
4
5
6
7
8
9
10
A
Exhaust cover
No. Part name Q’ty Remarks
1Bolt 6 M6 × 30 mm
2 Rectifier Regulator 1
3Gasket 1
Not reusable
4Bolt 1 M6 × 16 mm
5 Holder 1
6Bolt 3 M6 × 30 mm
7Thermoswitch 1
8Cover 1
9Thermostat 1
10 Gasket 1
Not reusable
11 Exhaust cover 1
12 Gasket 1
Not reusable
13 Screw 7 M5 × 27 mm
14 Anode 7
15 Holder 1
16 Bolt 1 M6 × 12 mm
17 Gasket 1
Not reusable
1
2
3
11
12
13
14
17
18
19
20
21
22
22
23
23
24
25
26
27
28
29
30
31
32
a
b
6 N m (0.6 kgf m, 4.4 ft lb)
12 N
m (1.2 kgf m, 8.9 ft lb)
55 N m (5.5 kgf m, 40.6 ft lb)
23 N m (2.3 kgf m, 17.0 ft lb)
15
16
6
8
9
10
7
4
5
a
b
6 N m (0.6 kgf m, 4.4 ft lb)
12 N
m (1.2 kgf m, 8.9 ft lb)
Camshaft / Exhaust cover
