Yamaha F150B - Wiring Diagram

A-2
0
1
2
3
5
6
7
8
9
10
10
10
A
Wiring diagram
How to use the wiring diagram
Composition of the wiring diagrams
The wiring diagram consists of three categories. Fuel unit, Ignition unit, Charging and starting unit.
Legend symbols in the wiring diagrams
a
Double colors wire
b No wire connector
c A wire is not included in the selected wiring unit.
d Alert buzzer
e Option parts
Color Code
B : Black G/R : Green/Red
Br : Brown G/Y : Green/Yellow
G : Green L/G : Blue/Green
L : Blue L/W : Blue/White
Lg : Light green L/Y : Blue/Yellow
O : Orange P/B : Pink/Black
P : Pink P/G : Pink/Green
R : Red P/W : Pink/White
Sb : Sky blue Pu/B : Purple/Black
W : White Pu/G : Purple/Green
Y : Yellow Pu/R : Purple/Red
B/O : Black/Orange Pu/Y : Purple/Yellow
B/W : Black/White R/Y : Red/Yellow
B/Y : Black/Yellow W/B : White/Black
Br/W : Brown/White W/R : White/Red
G/B : Green/Black Y/G : Yellow/Green
BZ
a
b
c
de
