6-33
FUEL
Fuel system
2. Check the needle valve. Replace needle
valve assembly if bent or worn.
3. Check the float. Replace if there is deteri-
oration.
4. Check the filter. Clean if there is dirt or
residue.
Assembling the vapor separator
1. Install the needle valve assembly and
float to the cover assembly, and then
insert the float pin a in the direction a.
2. Check the float for smooth operation.
3. Check the float height. See “Checking
the vapor separator” (6-32) step 1.
4. Assemble the vapor separator. See
exploded diagram (6-29).
a
a
