Yamaha F150B - Engine Speed Control System; PTT System

1-8
Electrical technical data
0
1
2
3
4
5
6
7
8
9
10
A
Engine speed control system
(*1) The figures are for reference only.
PTT system
(*1) The figures are for reference only.
Item Unit
Model
F150B FL150B
Oil pressure sensor
Input voltage V 4.75–5.25
Output voltage (*1)
at 450.0 kPa (4.50 kgf/
cm
2
, 65.3 psi) and 60 °C
(140 °F) with SL 10W-30
engine oil and at 700 r/
min
V2.8
TPS
Output voltage (*1)
with throttle valve fully
closed TPS1
V0.703
with throttle valve fully
open TPS1
V4.255
Throttle valve opening angle
(*1)
with throttle valve fully
closed
Degree 0.1
with throttle valve fully
open
Degree 88.6
Input voltage V 4.75–5.25
Shift-cut switch
Input voltage V 4.75–5.25
Resistance (*1)
at 20 °C (68 °F) kΩ 4.465–4.935
Item Unit
Model
F150B FL150B
Trim sensor
Free position resistance (*1) Ω 238.8–378.8
Setting resistance (*1) Ω 9.0–11.0
