1-9
SPEC
Specification
Charging system
(*1) The figures are for reference only.
Starting system
Item Unit
Model
F150B FL150B
Lighting coil
Output peak voltage
at cranking (unloaded) V 11.0
at 1500 r/min (unloaded) V 50.0
at 3500 r/min (unloaded) V 110.0
Resistance (*1)
at 20 °C (68 °F) Ω 0.2–0.3
Fuse A 50
Rectifier Regulator
Output peak voltage
at 1500 r/min (loaded) V 13.0
at 3500 r/min (loaded) V 13.0
Item Unit
Model
F150B FL150B
Starter motor
Type Sliding gear
Output kW 1.4
Cranking time limit Second 30
Brushes
Standard length mm (in) 15.5 (0.61)
Wear limit mm (in) 9.5 (0.37)
Commutator
Standard diameter mm (in) 29.0 (1.14)
Wear limit mm (in) 28.0 (1.10)
Neutral switch
Input voltage V 4.75–5.25
