Yamaha F150B - Page 249

7-36
Cylinder head
0
1
2
3
4
5
6
7
8
9
10
A
Cylinder head
No. Part name Q’ty Remarks
1Plug 2
2Gasket 2
Not reusable
3 Cylinder head 1
4Gasket 1
Not reusable
5 Anode 2
6 Anode 2
7Screw 5 M6 × 16 mm
8 Anode 1
9 Collar 2
10 Exhaust valve 8
11 Intake valve 8
12 Valve shim 16
13 Valve lifter 16
14 Valve cotter 32
15 Valve spring retainer 16
16 Valve spring 16
17 Valve seal 16
Not reusable
1
2
3
4
5
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
a
b
19 N m (1.9 kgf m, 14.0 ft lb)
37 N
m (3.7 kgf m, 27.3 ft lb)
a
b
14 N m (1.4 kgf m, 10.3 ft lb)
28 N
m (2.8 kgf m, 20.7 ft lb)
c
90
25 N m (2.5 kgf m, 18.4 ft lb)
6
7
9
Exhaust cover / Cylinder head
