Yamaha F150B - Page 259

7-46
Cylinder block
0
1
2
3
4
5
6
7
8
9
10
A
No. Part name Q’ty Remarks
18 Oil pressure sensor 1
19 Oil filter 1
20 Joint 1
21 Bolt 4 M6 × 40 mm
22 Oil filter bracket 1
23 O-ring 2
Not reusable
24 Relief valve 1
25 Plug 1
26 O-ring 1
Not reusable
27 Plug 2
28 Bolt 10 M8 × 35 mm
29 Crankcase cover 1
30 Bolt 2 M6 × 25 mm
31 Gasket 1
Not reusable
32 Bolt 2 M6 × 45 mm
33 Oil filler neck 1
34 O-ring 1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40
41
42
42
43
43
44
45
a
b
7 N m (0.7 kgf m, 5.2 ft lb)
31 N
m (3.1 kgf m, 22.9 ft lb)
a
b
18 N m (1.8 kgf m, 13.3 ft lb)
31 N
m (3.1 kgf m, 22.9 ft lb)
54 N m (5.4 kgf m, 39.8 ft lb)
18 N m (1.8 kgf m, 13.3 ft lb)
34 N m (3.4 kgf m, 25.1 ft lb)
12 N m (1.2 kgf m, 8.9 ft lb)
12 N m (1.2 kgf m, 8.9 ft lb)
15 N m (1.5 kgf m, 11.1 ft lb)
23 N m (2.3 kgf m, 17.0 ft lb)
4 N m (0.4 kgf m, 3.0 ft lb)
38
39
