Yamaha F150B - Page 367

9-2
Shift rod and shift bracket
0
1
2
3
4
5
6
7
8
9
10
A
1 N m (0.1 kgf m, 0.7 ft lb)
2.5 N m (0.25 kgf m, 1.84 ft lb)
2.5 N m (0.25 kgf m, 1.84 ft lb)
19 N m (1.9 kgf m, 14.0 ft lb)
2
1
2
2
3
3
9
2
4
4
5
6
7
8
10
11
11
12
13
14
15
16
17
18
18
19
20
21
22
23
24
25
26
27
28
29
18 N m(1.8 kgf m, 13.3 ft lb)
No. Part name Q’ty Remarks
18 Washer 2
19 Bracket 1
20 Ball 1
21 Spring 1
22 Bolt 1
23 Pin 1
24 Grease nipple 1
25 Bushing 1
26 O-ring 1
Not reusable
27 Bolt 1 M6 × 35 mm
28 Shift rod 1
29 Bushing 1
