YASKAWA E-S Series - Page 276

11.1 List of Parameters
11.1.2 List of Parameters
11-26
PnBD6
2
/ZONE0
(ZONE Output 0)
Signal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-18
PnBD7
2
/ZONE1
(ZONE Output 1)
Signal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-18
PnBD8
2
/ZONE2
(ZONE Output 2)
Signal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-18
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Turn ON (close) the output when ZONE output 0 is 1.
1 Turn OFF (open) the output when ZONE output 0 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when ZONE output 1 is 1.
1 Turn OFF (open) the output when ZONE output 1 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output when ZONE output 2 is 1.
1 Turn OFF (open) the output when ZONE output 2 is 1.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
