YASKAWA E-S Series - Page 275

11.1 List of Parameters
11.1.2 List of Parameters
11-25
11
Parameter List
PnBD3
2
/PAREA
(Program-
Specified Area
Signal)
Allocation
0000h to
00C2h
− 00A0h
After
restart
Setup page 5-17
PnBD4
2
/S-ONS
(SERVO ON Sta-
tus Output)
Signal Allocation
0000h to
00C2h
− 00B0h
After
restart
Setup page 5-17
PnBD5
2
E-STPS
(Emergency Stop
Status Output)
Signal Allocation
0000h to
00C2h
− 00C1h
After
restart
Setup page 5-17
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Turn ON (close) the output within the program-specfied area.
1 Turn OFF (open) the output within the program-specfied area.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output in the SERVO ON state.
1 Turn OFF (open) the output in the SERVO ON state.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output during emergency stop status.
1 Turn OFF (open) the output during emergency stop status.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
